Conformal Coating
PCB Protection

Description
INTERTRONICS supplies a range of conformal coating for printed circuit protection. Conformal coatings are materials applied in thin layers (typically 0.1 to 0.3mm) onto printed circuit boards or other electronic substrates. They provide environmental and mechanical protection to significantly extend the life of the assembly. Conformal coatings are traditionally applied by dipping, spraying or simple brushing, and increasingly by select coating or robotic dispensing.

Conformal coatings protect pcb's from moisture and contaminants, preventing short circuits and corrosion of conductors and solder joints. They also minimise dendritic growth and the electromigration of metal between conductors. The use of conformal coatings protects circuits and components from abrasion and solvents. Stress relief can be provided, as well as protection of the insulation resistance of the circuit.

Product Index
	Turbo-Coat Acrylic Conformal Coating is a fast cure acrylic conformal coating
	DYMAX Conformal Coatings are fast UV curing products Video available
	ACC offer a number of conformal coating chemistries, with conventional cures  ACC 11 Acrylic Conformal Coating - aerosol (63Kb)  ACC 12 Polyurethane Conformal Coating - aerosol (61Kb)  ACC 14UV Silicone Conformal Coating - bulk (140Kb)
	Techspray Fine-L-Kote SR is a silicone conformal coating available in aerosol or bulk (105Kb)
	Conformal Coating Masking Tapes A range of masking tapes for conformal coatings

November 2009
Version 2.1
