UV & Visible Light Curing
Plastic Bonding Adhesives
- Bond in seconds
- Environmentally friendly
- UV and visible light curing adhesives
Description
DYMAX UV Light Curing Plastic Bonding Adhesives cure in seconds
upon exposure to ultraviolet light and/or visible light,
even through UV blocked plastics. A solvent-free, worker-friendly plastic
adhesive forms high-strength, environmentally resistant bonds to plastics
and other substrates, including polycarbonate, PVC, phenolic, acrylic (PMMA),
metal, glass and ceramic. Because plastic adhesives bond so many different
substrates, they are exceptional adhesives for bonding dissimilar materials,
something that cannot be done with traditional welding methods and other
types of adhesives. Typical UV plastic adhesive applications include display
case construction, automotive headlamp assembly, novelty bonding, sign
assembly, adhering light fixtures and awards and plastic package assembly.
| Product Selector Guide | ||
|---|---|---|
| Adhesive | Applications | Adhesive features |
| Most popular, core products | ||
| DYMAX 3094 | Bonding display cases, shelves; laminating plastic sheets; packaging; bonds to acrylic, ABS, styrene, polycarbonate, polyurethane | UV light and/or visible light curing; dispenses easily and cures quickly for precise quantity and placement of adhesive; bonds generally exceed the strength of substrates bonded, including PVC alloys, which resist most other bonding methods |
| DYMAX 3099 | Bonding clear and translucent acrylic, PMMA, polycarbonate, PVC alloys, and polyurethane. Bonding point-of-sale plastics | Resilient adhesive with excellent adhesion to acrylic (PMMA). Clear, low viscosity UV cured adhesive produces clear, bubble-free bondlines. Can be cured with the DYMAX BlueWave LED |
| See-Cure Adhesive Technology | ||
| DYMAX 3220-SC | Bonding and laminating plastics including PVC, PC, ABS, PET, PEBA, and PU | See-Cure adhesives appear blue when dispensed and become clear when fully cured. This allows users to know where the adhesive has been applied, as well as if the adhesive is fully cured; flexible |
| DYMAX 3221-SC | Bonding and laminating plastics including PMMA, PVC, PC, PU, PA, PET, and ABS | See-Cure adhesives appear blue when dispensed and become clear when fully cured. This allows users to know where the adhesive has been applied, as well as if the adhesive is fully cured; flexible; multi-substrate adhesion |
| DYMAX 3222-SC | Appliance assembly; plastics lamination; metal-to-plastic bonding; bond joint & sealing; plastic window bonding. PC, PMMA, PVC, PU, PA, metals, glass | See-Cure adhesives appear blue when dispensed and become clear when fully cured. This allows users to know where the adhesive has been applied, as well as if the adhesive is fully cured; flexible; multi-substrate adhesion |
| DYMAX 3224-SC | Industrial plastics bonding; film laminating; strain relief; connectors and hoses | See-Cure adhesives appear blue when dispensed and become clear when fully cured. This allows users to know where the adhesive has been applied, as well as if the adhesive is fully cured; flexible; multi-substrate adhesion |
| Other plastic bonders | ||
| DYMAX 3013 | Bonding transparent or translucent acrylic, metal, polycarbonate, PVC alloys, ABS, polyurethane and polystyrene | Resilient; general purpose; low viscosity; moisture resistant; flexible; dispenses easily and cures quickly for precise quantity and placement of adhesive; built-in fluorescence provides a method to insure in-line quality control utilizing optical scanners |
| DYMAX 3021 | High strength UV epoxy; bonds glass, various plastics and most metals | Low shrinkage (<0.2%); resists yellowing; maintains dimensions with minimal degradation of strength when thermally cycled; cures fully in seconds upon UV/visible light exposure, but heating the cured product to 150°C for 1 hour will increase the Tg to 100°C and may further improve bond strength. Can be cured with the DYMAX BlueWave LED |
| DYMAX 3025 | Bonding polycarbonate; flexible and rigid PVC; ABS; acrylic; stainless steel | Moisture resistant; solvent-free; rapid cures; low viscosity |
| DYMAX 3125-UR | Plastic housing assembly; plastic window bonding; appliance assembly | Ultra-Red fluorescing under a low-intensity "black" light; adhesion to a wide variety of glass, metals, and plastics; moisture resistant |
| DYMAX 3069 | Electrical bonding; potting; wire harness assembly; bonds to polycarbonate, PVC, polyurethane, PET | Low stress; clear; environmentally resistant; adheres to most surfaces; good for flexible and rigid substrates |
| DYMAX 3070 | Bonding rigid fittings to flexible tubing; adheres to PVC, SAN, PBT, polycarbonate, styrene, mylar, polyester | High water and moisture resistance at elevated temperatures; NVP-free; flexibility provides shock absorbing capabilities in the bond area |
| DYMAX 3072 | Electrical potting and sealing; bonds to PBT, Valox®, metal, glass, PVC, SAN, PS and K-Resin® | UV and/or visible light curing; dispenses easily to allow for precise quantity and placement of adhesive; bonds generally exceed the strength of substrates bonded, including PVC alloys, which resist most other bonding methods. Can be cured with the DYMAX BlueWave LED |
| DYMAX 3081 | Sealing PVC clamshell packages | Strong bonds to thermoformed PVC |
| DYMAX 3083 | Sealing PET & R-PET clamshell packages | Strong bonds to thermoformed PET and R-PET |
| DYMAX 3086 | Packaging; bonds to SAN, ABS, CAP, MBS, acrylic, glass, ceramic and metal | Very fast; structural strength adhesive; hard, rigid bonds; UL94 V-0 flame class rating |
| DYMAX 3089 | Laminating and bonding; adheres to PET, glass PETG, Mylar®, K-Resin®, PP and brass | Low stress; very fast curing; flexible UV adhesive; resilient bonds exhibiting high flexibility to minimize or eliminate bond line stresses. Excellent polyester (Mylar) bonder |
| DYMAX 3091 | Low stress plastic bonder; rapid bonding of PVC, acrylic, nylon, PC, PU, styrene | Dispenses easily; moisture resistant; multi-substrate adhesion; extremely fast curing |
| Substrate Selector Guide | ||||||||||||||||
| Plastics | ||||||||||||||||
| Product | ABS | FR-4 | LDPE | PA | PBT | PC | PEI | PES | PETG® | PI | PMMA | PPO | PP | PPS | PS | PSU |
| 3013 |  |
|
|
|
|
|||||||||||
| 3021 |  |
|
* |
|
* |
* |
* |
* |
* |
* |
* |
|||||
| 3220-SC | |
|
|
|
|
|
|
|
||||||||
| 3221-SC | |
|
|
|
|
|
|
|
||||||||
| 3222-SC | |
|
|
* |
* |
* |
|
|
|
|
|
|||||
| 3224-SC | |
|
* |
|
|
|
|
|
||||||||
| 3025 | |
|
|
|
* |
|||||||||||
| 3069 | |
|
|
|
|
|
|
|
* |
|
|
|||||
| 3070 | |
* |
|
|
|
|
||||||||||
| 3072 | |
|
|
|
|
|
|
|
|
|
|
|||||
| 3086 | |
|
* |
|
|
|
|
|
|
|||||||
| 3089 | * |
* |
|
|
|
|||||||||||
| 3094 | |
|
* |
|
|
|
|
|
|
|
|
|
|
|
||
| 3099 | |
* |
|
|
|
|||||||||||
| Plastics | Metals | Non Metals | ||||||||||||||
| Product | PUR | PVC (Flexible) |
PVC (Rigid) |
SAN | AL | Cold Rolled Steel |
CU | Galvanised | Stainless Steel |
Zinc | Crystal | Glass | Ferrite | |||
| 3013 | |
|
|
|
|
|
|
|
||||||||
| 3021 | * |
* |
|
|
|
|
|
|
|
|
||||||
| 3220-SC | |
|
|
|||||||||||||
| 3221-SC | |
|
|
|
||||||||||||
| 3222-SC | |
|
|
|
|
|
|
|||||||||
| 3224-SC | |
|
|
|||||||||||||
| 3025 | |
|
|
|
||||||||||||
| 3069 | |
** |
|
|
|
|
|
|
|
|||||||
| 3070 | |
* |
|
|
||||||||||||
| 3072 | |
* |
|
|
|
|
|
|
|
|||||||
| 3086 | |
|
|
|
|
|
|
|
|
|
||||||
| 3089 | |
|
|
|
|
|
|
|||||||||
| 3094 | |
|
|
|
|
|
|
|
|
|||||||
| 3099 | |
|
|
|
|
|
|
|
||||||||
| = Good to Excellent Adhesion
= Fair to Good Adhesion
* = indicates improvement with surface treatment | ||||||||||||||||
| This guide represents only a small portion of the DYMAX adhesive library. Call us to help you select the appropriate adhesive for your specific application. Optimal curing of DYMAX UV adhesives requires a light source with peak intensity at 365 nm. Our light curing adhesives will also absorb visible light at 410-440 nm from the same light source for deeper and faster curing through UV inhibited or semi-opaque substrates. Recommendations should be used as a guide for evaluation and laboratory testing of particular substrate grades and applications. | ||||||||||||||||
| Substrate | Chemical name | Registered Trademark |
| ABS | Acrylonitrile-butadiene-styrene | Lustran ®, Terluran ®, Cycalloy ® |
| FR4 | Epoxy Fibreglass | |
| LDPE | Low-Density Polythene | |
| PA | Polyamide | Nylon* |
| PBT | Poly (butylene terephthalate) | Valox* |
| PC | Polycarbonate | Makrolon ®, Lexan®, Apec®, Calibre® |
| PEI | Polytherimide | Ultem® |
| PES | Polyester Sulfone | Ultrason®, Udel® |
| PETG® | Copolyester | Easter® |
| PI | Polyimide | Kapton® |
| PMMA | Poly (Methyl Methacrylate) | Acrylic, Plexiglass®, Perspex®, Cryolite® |
| PP | Polypropylene | |
| POP | Poly (Phenylene Oxide) | Noryl® |
| PPS | Poly (Phenylene Sulfide) | Ryton® |
| PS | Polystyrene | Novacor®, Styron® |
| PSU | Polysulfone | Ultrason® |
| PUR | Polyurethane | |
| PVC | Polyvinyl Chloride | |
| SAN | Styrene-acrylonitrile | Lustran® |
| AI | Aluminium | |
| CU | Copper | |
| ® Registered trademarks and trademarks acknowledged. | ||
