Automatic Liquid Dispenser
Adhesive Dispenser
Dispensing Controller
- Timing intervals from 0.01 to 31 seconds
- Versatile design for wide range of dispensing applications
- Barrel "suck-back" ensures no dripping on low viscosity materials
- Ready to use - everything included
Only
£349.00!
Description
The FIS JB1113N Automatic Liquid Dispenser, with its versatile
design, is perfectly suited to a wide variety of dispensing applications,
making it our most popular dispenser. A variable timed interval from
0.01 seconds to 31 seconds allows for dispensing from microdot deposits to large
potting and filling. Adjustable barrel suck-back ensures control of the dripping
associated with dispensing of low viscosity materials.
 |
||
| The JB1113N dispenses in continuous beads or in timed shots at the flick of a switch. |
The FIS JB1113N's high speed control of up to 600+ cycles per minute with its excellent repeat tolerances make it an excellent choice for dispensing a wide range of assembly materials such as solder paste, masking materials, potting materials, encapsulants, UV curable materials, silicones, oils and adhesives, solvents, greases, liquid gasket material, RTVs and many more.
All set up hoses and fittings, along with barrels and tips, are included, making the unit ready to use right out of the box.
Used in the following industries:
- Automotive
- Semiconductor
- Loudspeakers
- PCB assembly
- Medical devices
- Jewelry
- Sensor manufacturing
- Connectors
- Flat panel displays
- SMT
- General automation
- and many more!
 |
|
 |
| Specifications | |
| Size | 22 x 21 x 6.7 cm |
| Digital timer | User programmable intervals (dip switch) Five selectable ranges from 0.005 to 31 seconds |
| Cycle initiation | Maintained or momentary |
| Input voltage | 90-260 VAC |
| Internal & foot pedal voltage | 24V dc |
| Cycle speed | 600+/minute |
| Air input | 70-100 psi (5-7 bar) |
| Air output | 1-100 psi (0.1-7 bar) |
| Standards | European CE approved unit |
| The FIS JB1113N requires compressed air to function | |
The FIS JB1113N comes complete with a universal Dispensing Component Kit, a selection of the most typically used dispensing components. All consumable dispensing components are readily available.
| Ordering information | ||
| Part number | Description | |
| FISJB1113N | Automatic Liquid Dispenser | |
Other information
 |
 Download the complete Fisnar Dispenser Catalogue |
 |
See also! Dispensing
barrels & accessories - essential consumable items for your dispenser Dispensing needles & tips - we have many options Digital adhesive dispenser - the next step up the scale in dispensers
|
 |
Obtain more information, samples or literature |
 |
Contact details and how to order |
